3. Specifications
The Snor kel EPV12J is a boom sup ported el e vat ing work plat form built to con form to all ap pli ca ble OSHA,
ANSI or CSA stan dards as pre vi ously out lined.
OSHA Para graph 1910.67 Ti tle 29, C.F.R., Ve hi cle-Mounted El e vating and Ro tating Work Plat forms - La -
bour.
OSHA Para graph 1926.556 Ti tle 29, C.F.R., Ae rial Lifts - Con struc tion.
Aus tra lian Stan dard AS1418-10 1996 El e vating Work Plat forms.
NOTE:
For further details regarding lubricants, maintenance schedules and service please refer to the
Maintenance and repair Parts Manual for this machine.
■ General Specifications
SPECIFICATIONS
EPV12J
Nominal working height
12.8m
40’ 8”
Maximum height to basket floor
11m
34’ 1”
Maximum outreach
5.4m
17’ 9”
Maximum outreach height
6.5m
18’ 6”
Nominal width of base
2m
6’ 5”
Safe working load (unrestricted)
200kg
440lbs
Standard colour
Charcoal base / white booms
Platform size
1200 x 760 x 1100mm
Aluminum
4’ x 2’ 6” x 3’ 7”
Aluminum
Nominal travelling height
2750mm
6’ 8”
Nominal overall length
7315mm
18’ 8”
Turntable rotation
550 degrees non-continuous
Insulation rating
Optional 5KV
Nominal weight
1500kg
2609lbs
■ Recommended Hydraulic Oil
Shell Tellus 32 or Castrol AWS 32 or similar
EPV12J – 12246A
page 3 - 1
