Controls and Indicators 500315-005
TL38 Operator Manual Page 5
C
ONTROLS AND
I
NDICATORS
Figure 2: Controls and Indicators
Platform Controls
Chassis Controls
1
2
3
4
5 6
7
{
1
2 3 4
5
1.Emergency stop
2.Telescope
3.Upper Boom
4.Lower Boom
5.Rotate
6.Display
7.Joystick
1.Emergency stop
2.Machine Controls
3.Outrigger Controls
4.Analog Rocker
5.Key Switch
{
