Introduction 500315-005
TL38 Operator Manual Page 3
I
NTRODUCTION
This manual covers operation of the TL50 Work Platforms. This manual must be stored on the machine
at all times.
G ENERAL D ESCRIPTION
Figure 1: TL 38
1. Platform
W A R N I N G ! !
DO NOT use the maintenance platform
without guardrails properly assembled
and in place
2. Elevating Assembly
3. Chassis
4. Power Module
5. Control Module
6. Platform Controls
7. Manual Case
8. Chassis Controls
9. Hydraulic Fluid Reservoir
10. Batteries
1 2
3 4 5
6
7
8
9
10
