Introduction 505562-100
SR2684SL & SR3084SL Page 3
I
NTRODUCTION
This manual covers operation of the SR2684SL & SR3084SL Series Self-Propelled Work Platforms.
This manual must be stored on the machine at all times.
G
ENERAL
D
ESCRIPTION
W A R N I N G ! !
DO NOT use the maintenance platform without guardrails properly assembled and in place
Figure 1: SR2684SL & SR3084SL
1. Platform
2. Elevating Assembly
3. Chassis
4. Power Module
5. Control Module
6. Platform Controls
7. Manual Case
8. Chassis Controls
9. Hydraulic Fluid Reservoir
1
2
3
4
5
6 7
8
9
