12
SL20
*Specifications are subject to change without notice. Hot weather or heavy use may affect performance.
Refer to the Service Manual for complete parts and service information. The SL20 meets or exceeds all
applicable CE and GS machinery directive requirements.
S PECIFICATIONS
ITEM SL20
Platform Size (Inside toeboards) 0.74 m x 2.53 m (29 in. x 99.5 in.) Inside Toeboards
Maximum Platform Capacity
Standard w/ Extension 340 kg (750 lbs.)
on Extension 110 kg (250 lbs.)
Maximum Number of Occupants
Standard w/ Extension 2 People
on Extension 1 person
Height
Working Height 8.1m (26.5 ft.)
Maximum Platform Height 6.10 m (20 ft.)
Maximum Drivable Height 6.10 m (20 ft.)
Dimensions
Weight, Standard 1411 kg (3100 lbs.)
Overall Width 0.84 m (33 in.)
Overall Height 2.1 m (82.6 in.)
Overall Length, Standard 2.75 m (107.5 in.)
Drive Speed
Platform Lowered 3.70 km/h (2.3 mph)
Platform Raised 1.0 km/h (0.61 mph)
Energy Source 24 V Battery Pack (4-220 A Hour, 6 V Batteries,
Minimum Weight 28 kg [62 lbs.] each),
4 HP DC Electric Motor
System Voltage 24 V DC
Battery Charger 25 A
Hydraulic Tank Capacity 15.2 L (4 US gal.)
Maximum Hydraulic System Pressure 207 bar (3000 psi)
Hydraulic Fluid
Above 0°C (32°F) ISO #46
Below 0°C (32°F) ISO #32
Below -17°C (0°F) ISO #15
Lift System Single Lift Cylinder
Lift Speed 14 seconds
Control System Motor Control, Rotary Selector Switch, and Red Mushroom Emergency
Stop Switch
Drive System Dual Front Wheel Hydraulic Motors
Tires 381 mm (15 in.) Diameter Solid Rubber, non-marking
Parking Brakes Dual – Spring Applied, Hydraulically Released
Turning Radius (inside) 0.64 m (25 in.) Inside
Maximum Gradeability 25% (14 ° )
Wheel Base 1.78 m (70 in.)
Guardrails 1.02 m (40 in.)
Toeboards 152 mm (6 in.)
