Introduction
4 SB85J Fixed Axle – 0112998
Introduction
This manual covers the SB85J Fixed Axle Aerial Work
Platform.
This manual must be stored on the machine at all
times.
Read, Understand and follow all safety rules and op-
erating instructions before attempting to operate the
machine.
When contacting UpRight for service or parts information,
be sure to include the MODEL and SERIAL NUMBERS
from the equipment nameplate. Should the nameplate
be missing, the SERIAL NUMBER is also stamped at
the rear of the chassis.
Right Side
Chassis
Lower Controls
Upper Controls
LP Fuel Tank
Operator’s
Manual
Wiring Box
Steer Wheels
Left Side
Platform
Main Boom
Tip Boom
Hydraulic Fluid Tank
And Filter
Battery Disconnect
Switch
Batteries
Engine
Steer Wheels Platform
Foot Switch
Emergency
Lowering
Valve
Intermediate
Boom
Jib
Fuel Tank
Nameplate
Location
Component Identification
