Operation

12

SB85J Fixed Axle – 0112998

Use four wheel coordinated steer when a tight turn-

ing

radius is desired for positioning the machine.

Use crab steer to travel in a diagonal motion in the

direction of the wheels.

Note

The steering wheels are not self-centering. Set the steer-

ing wheels straight ahead after completing a turn and

before switching from one steer mode to another.

3. Place the drive/boom selector switch in the drive

position.

4. Step down on the platform foot switch.

5. Push the drive joystick forward to move the chas-

sis forward, the direction of the blue arrow. Pull the

joystick backward to move the chassis backward,

the direction of the yellow arrow. The drive speed is

proportional to the joystick position.

6. To stop drive motion, return the joystick to neutral.

7. Push the drive joystick to the right to steer to the right,

the direction of the yellow arrow. Push the joystick

to the left to steer to the left, the direction of the blue

arrow.

Note

The steering wheels are not self-centering. Set the steer-

ing wheels straight ahead after completing a turn.

8. After driving to the desired location, release the foot

switch, or push the emergency stop button to apply

the parking brakes.

Drive Speeds

The drive speed is proportional to the joystick position.

The farther the joystick is moved, the faster the travel

speed.

Always slow down and shift the drive system to low

range before traveling over rough terrain or any sloped

surface.

Drive speed ranges are interlocked through a limit switch

that senses the main boom position. When the boom is

elevated, only the slowest drive speed will work regard-

less of the drive range switch position.

A

Warning

The potential for an accident increases when safety

devices do not function properly. Death or serious

injury can result from such accidents. Do not alter,

disable or override any safety device.

Do not use the aerial platform if it drives faster than

1.0

km/h (0.6 miles per hour) [7.9 m (26 feet) in 30 seconds]

when the booms are elevated from the stowed position.

Motion Warning Alarm

The optional motion warning alarm sounds loud intermit-

tent beeps when the drive joystick is in the forward or

reverse position.

AC Generator

The optional generator supplies power to the electrical

outlet only when the engine is running and the machine

is stationary. The machine functions will not operate when

the machine/generator selector switch is in the generator

position.

A

Caution

Cold hydraulic oil does not flow well and may produce

improper generator output voltage. Improper outlet

voltage can damage some electrical power tools and

equipment. Warm the hydraulic oil before operating

the generator.

Do not operate the generator unless the hydraulic oil tem-

perature is at least 38°C (100°F). Refer to Cold Weather

Start-Up for a hydraulic oil warm-up procedure.

Start the engine and place the machine/generator selec-

tor switch in the generator position (ref: upper controls

illustration on page 6).

The engine will run at high idle while the generator is

operating. The generator will continue to operate as long

as the engine is running and the switch is in the genera-

tor position.

Dual Fuel

The dual fuel switch is located on the front of the lower

control panel.

Before starting the engine, place the fuel switch in the

gasoline or the LPG position. Open the shut-off valve on

the LPG gas tank if using LPG. Always keep the LPG tank

shut-off valve closed when not using LPG.

To switch from gasoline to LPG with the engine running:

1. Open the shut-off valve on the LPG tank.

2. Place the fuel switch in the LPG position.

To switch from LPG to gasoline with the engine running:

1. Place the fuel switch in the gasoline position.

2. Close the shut-off valve on the LPG tank.

Air Line

The optional air line may be used to conduct air for tool

operation at the platform. The input connector is at the

rear of the chassis and the output connector is at the

platform on the rotator guard. The maximum working

pressure of the line is 1,723 kPa (250 psi).
