Snorkel MX19-sn20000-20599ANSI User Manual
Page 6
Page 4
060570-008 MX15 / MX19 - Operator Manual
Controls and Indicators
C
ONTROLS
AND
I
NDICATORS
Figure 2: Controls and Indicators
1
3
4
5
6
2
1
5
3
2
4
1 Circuit Breaker
2. Chassis Key Switch
3. Chassis Lift/Lower Switch
4. Chassis Emergency Stop Button
5. Hour Meter/Voltage Indicator
1. Steering Switch
2. Interlock Switch
(on front of Control Handle)
3. Control Handle
4. Platform Emergency Stop Switch
5. Lift Drive Selector Switch
6. Optional Horn Button Location
Platform Controls
Chassis Controls
