Page 16 060570-008 MX15 / MX19 - Operator Manual
Specifications
S PECIFICATIONS
*Specifications are subject to change without notice. Hot weather or heavy use may affect performance.
Refer to the Parts Manual and the Service Manual for complete parts and service information.
The MX15/19 meets or exceeds all applicable requirements of OSHA and ANSI A92.6-1999.
ITEM MX15 MX19
Platform Size (Inside minimum)
Standard w/Deck 0,72 m x 2,54 m (28.5 in. x 100 in.) 0,72 m x 2,54 m (28.5 in. x 100 in.)
Maximum Platform Capacity
Standard w/Deck Extension 250 kg (550 Lbs.) 227 kg (500 Lbs.)
Maximum Number of Occupants
Standard w/Deck Extension 2 People 2 People
on Extension 1 Person 1 Person
Height
Working Height 6,4 m (21 ft.) 7,62 m (25 ft.)
Maximum Platform Height 4,57 m (15 ft.) 5,8 m (19 ft.)
Maximum Drivable Height 4,57 m (15 ft.) 5,8 m (19 ft.)
Dimensions
Weight 1343 kg (2960 Lbs.) 1465 kg (3230 Lbs.)
Overall Width 760 mm (30 in.) 760 mm (30 in.)
Overall Height (Lowered) 1,89 m (74.5 in.) 2,01 m (79.25 in.)
Overall Length (Deck in) 1,75 m (68.75 in.) 1,75 m (68.75 in.)
Drive Speed
Platform Lowered 3,7 km/h (2.3 mph) 3,7 km/h (2.3 mph)
Platform Raised 1,0 km/h (0.62 mph) 1,0 km/h (0.62 mph)
Energy Source
24 V battery pack (4-220 A hour,
6 V batteries, min. wt. 26,3 kg [58 Lbs.]
each), 4 HP DC electric motor
24 V battery pack (4-220 A hour,
6 V batteries, min. wt. 26,3 kg [58 Lbs.]
each), 4 HP DC electric motor
System Voltage 24 V DC 24 V DC
Battery Charger 20 A, 110/220 VAC 20 A, 110/220 VAC
Hydraulic Reservoir Capacity 12,9 L (3.4 US gal.) 12,9 L (3.4 US gal.)
Maximum Hydraulic System Pressure 207 bar (3000 psi) 207 bar (3000 psi)
Hydraulic Fluid
Normal above 32° F [0° C] ISO #46 ISO #46
Low Temp. below 32° F [0° C] ISO #32 ISO #32
below 0° F [-17° C] ISO #15 ISO #15
Lift System One Single Stage Lift Cylinder One Single Stage Lift Cylinder
Drive Control Motor Control Motor Control
Control System
Control Handle with Interlock Switch,
Rotary Drive/Lift Switch, and Red
Mushroom Emergency Stop Switch
Control Handle with Interlock Switch,
Rotary Drive/Lift Switch, and Red
Mushroom Emergency Stop Switch
Drive System Dual Front Wheel Hydraulic Motors Dual Front Wheel Hydraulic Motors
Tires
30,5 cm (12 in.) diameter solid rubber,
Non-marking
30,5 cm (12 in.) diameter solid rubber,
Non-marking
Parking Brake Dual, Spring Applied, Hydraulic Release Dual, Spring Applied, Hydraulic Release
Turning Radius (inside) 150 mm (6 in.) Inside 150 mm (6 in.) Inside
Maximum Gradeability 29% (16°) 29% (16°)
Wheel Base 1,23 m (48.5 in.) 1,23 m (48.5 in.)
Guardrails 1,10 m (43 in.) 1,10 m (43 in.)
Toeboard 150 mm (6 in.) 150 mm (6 in.)
