Introduction
060570-008 MX15 / MX19 - Operator Manual Page 3
I NTRODUCTION
This manual covers the application of the MX15 and MX19 Aerial Work Platforms. This manual must be
stored on the machine at all times.
Read, understand and follow all safety rules and operating instructions before attempting to operate the
machine.
G ENERAL D ESCRIPTION
W A R N I N G ! !
DO NOT use the machine without guardrails properly assembled and in place.
Figure 1: MX Series
1. Platform Controls
2. Manual Case
3. Deck Extension
4. Platform
5. Elevating
Assembly
6. Chassis
7. Batteries
8. Charger Outlet
Plug
9. Chassis Controls
10. Emergency
Lowering Valve
Knob
11. Hydraulic Fluid
Reservoir
2
1
3
4
5
7
6
8
9
10
11
10
11
Front
