Snorkel AB62RT User Manual
Page 42
42
ENGLISH
FRANCAIS
GERMAN
SPANISH
1
Cylinder
Vérin
Linder
Cilindro
2
Motor
Moteur
Motor
Motor
3
Pump
Pompe
Pumpe
Bomba
4
Filter
Filtre
Filter
Filtro
5
Valve
Soupape
Ventil
Válvula
6
Relief Valve
Soupape de décharge
Überdruckventil
Válvula de alivio
7
Counterbalance Valves
Soupapes d'équilibrage
Ausgleichsventile
Válvulas de contrapeso
8
Flow Divider
Vanne Distributrice
Strömungsteiler
Divisor de Flujo
9
Accumulator
Accumulateur
Akkumulator
Acumulador
10
Orofice
Orofice
Drosselblende
Oroficio
Hydraulic Schematic, AB62 - 104048-000
