10
COMPONENT INSPECTION OR SERVICES INTERVAL A N R
Engine Oil Check level and condition Daily
Check for leaks Daily
Change oil & filter (Dual Fuel) 200 HOURS
Change oil & filter (Diesel) 500 HOURS
Engine Fuel Check fuel level Daily
System Check for leaks Daily
Replace fuel filter 6 M
Check air cleaner Daily
Battery Check electrolyte level Daily
Clean exterior 3 M
Clean terminals 3 M
Engine Check coolant level (with engine cold) Daily
Coolant Replace coolant 3 M
Hydraulic Check oil level Daily
Fluid * Change filter 6 M
Drain and replace with ISO 46 compatible oil 2 Y
Hydraulic Check for leaks Daily
System Check hose connections 30 D
Check hoses for exterior wear 30 D
Emergency Check operation of emergency override Daily
Hydraulic valves and hand pump
System Check operation of emergency override power unit Daily
Controller Check operation of all controls Daily
Control Check the exterior of the cable Daily
Cable for pinching, binding or wear
Platform Check fasteners for proper torque Daily
Floor and Check welds for cracks Daily
Rails Check condition of platform Daily
Check condition of anchorage points Daily
Check condition of operators manual Daily
Tires Check for damage Daily
Check air pressure 5.5 bar [80 psi]) Daily
Check lug nuts (torque to 123 Nm [90 ft. lbs.]) 30 D
Hydraulic Wipe clean 30 D
Pump Check for leaks at mating surfaces 30 D
Check for hose fitting leaks Daily
Check mounting bolts for proper torque 30 D
Hydraulic Check hydraulic drive motor operation Daily
Drive Check hoses, fittings, and valve block
System for leaks
Daily
Routine Service Table Key
Interval
Daily = each shift (every day) or every eight hours
30
D = every month (30 days) or every 50 hours
3
M
= every 3 months or 125 hours
6
M
= every 6 months or 250 hours
1 Y = every year or 500 hours
2
Y
= every 2 years or 1000 hours
A = Acceptable
N = No / Not Acceptable
R = Repaired / Acceptable
Routine Service Table
Service Report
Date: _________________________________________
Owner: _______________________________________
Model No: ___________ Serial No: ________________
Serviced By: __________________________________
Service Interval: ________________________________
ROUTINE SERVICE
Use the following table as a guide for routine mainte-
nance. Inspection and maintenance shall be performed
by personnel who are trained and familiar with me-
chanical and electrical procedures. Refer to the Service
Manual for complete service instructions.
Please copy this page and use the Routine Service Table
as a checklist when inspecting a machine for service.
COMPONENT INSPECTION OR SERVICES INTERVAL A N R
Steering Check fittings for proper torque 6 M
System Oil all pivot points 30 D
Check steering cylinder for leaks 30 D
Check linkage for wear areas 30 D
Check for missing / loose retainers Daily
Elevating Inspect for structural cracks Daily
Assembly Check pivot points for wear 30 D
Check pivot pin retaining bolts
30 D
for proper torque
Check members for deformation
Daily
Chassis Check hoses for pinch or rubbing points Daily
Check component mounting for proper torque 6 M
Check welds for cracks Daily
Turret Check ring gear for proper lubrication and wear Daily
Lubricate ring gear (MoS2 grease) 150 H /3 M
Torque Check for leaks Daily
Hubs Check oil level 250 H /6 M
Change oil after break-in period 50 H /30 D
Change oil (SAE 90 gear oil) 2000 H /2 Y
Lift Check the cylinder rods for wear 30 D
Cylinders Check pivot pin retaining bolts
30 D
for proper torque
Check seals for leaks
30 D
Inspect pivot points for wear 30 D
Check fittings for proper torque 30 D
Entire Check for and repair collision damage Daily
Unit Check fasteners for proper torque 3 M
Check for corrosion, remove and repaint 3 M
Lubricate 30 D
Labels Check for peeling, missing, or unreadable Daily
labels & replace
*ISO grade 46, for temperatures above 32°F (0°C).
*For colder climates: ISO grade 32, for temperature range of 0 °F (-17° C)
up to 32° F (0°C).
*ISO grade 15, for temperatures below 0 °F (-17° C).
