25
11.3 Control desk (control unit + pedestal)
Designation
CT7-6/3DV CT7-6/4DV CT7-6/4DVV
(with pedestal) (with pedestal) (with pedestal)
Ref. no. 840721341 840721342 840721343
Comprising:
(ref. nos.)
840721344 840721345 840721346
840720325 840720325 840720325
Dimensions
(L x W x H)
[mm] 801 x 700 x 1100 931 x 700 x 1100 986 x 700 x 1100
[in.] 35.5 x 27.6 x 43.3 36.7 x 27.6 x 43.3 38.8 x 27.6 x 43.3
Weight
[kg] 44,5 52,0 59,3
[lbs.] 98.1 114.6 130.7
11.4 Recommended hydraulic fluids
Mineral oil DIN ISO 6743-4 for LUKAS hydraulic equipment and others
Oil temperature range Oil code Viscosity rating Remarks
A -24 .... +30°C HL 5 VG 5
B -18 .... +50°C HM 10 VG 10
C -8 .... +75°C HM 22 VG 22
D +5 .... +80°C HM 32 VG 32
E -8 .... +70°C HF-E15 VG 15 Bio-oil
Oil temperature range Oil code Viscosity rating Remarks
A -11.2 .... +86°F HL 5 VG 5
B -0.4 .... +122°F HM 10 VG 10
C +17.6 .... +167°F HM 22 VG 22
D +41.0 .... +176°F HM 32 VG 32
E +17.6 .... +158°F HF-E15 VG 15 Bio-oil
recommended viscosity range: 10...200 mm²/s (10…200 cSt.)
Supplied with HM 22 DIN ISO 6743-4.
11.5 Operating temperature and storage temperature ranges
Operating temperature [°C] -20 … +55
Ambient temperature (device in operation) [°C] -25 … +45
Storage temperature (device not in operation) [°C] -30 … +60
Operating temperature [°F] -4 … +131
Ambient temperature (device in operation) [°F] -13 … +113
Storage temperature (device not in operation) [°F] -22 … +140
