17
14 Technical data
14.1 Pump unit
14.2 Battery The working time with one battery under average rescue conditions is
30 to 45 min.
14.2.1 Technical data
14.3 Noise emission
14.4 Others
14.5 LUKAS Hoses
Voltage 24 VDC
Current max. 20 A
Motor power max. 480 W
Protection class IP 12
Hydraulic oil filling 1.6 l
Usable oil quantity 1.2 l
Oil delivery low pressure 1.33 l/min
Oil delivery high pressure 0.33 l/min
Dimensions (h x w x d) 570 x 179 x 174 mm
Weight (incl. oil filling) 18.8 kg
Temperature range -15 up to +50 °C
Working position vertically (with the battery downwards) - horizontal
position is also possible
Voltage 24 VDC
Current max. 20 A
Nominal capacity 9 Ah
Dimensions (l x w x h) 179 x 174 x 170 mm
Weight (battery only) 6.6 kg
Following the regulations of EN ISO 3744:
measuring distance above ground level 1.0 m
no load full load
Measuring distance 1 m 73 dB(A) 77 dB(A)
Measuring distance 4 m 62 dB(A) 68 dB(A)
Measuring distance 5 m 61 dB(A) 67 dB(A)
Working temperature -20 ... +55°C
Ambient temperature (power pack in operation) -24 ... +45°C
Storage temperature (power pack not in operation) -30 ... +60°C
Bending radius Rmin = 25 mm
Burst resistance safety factor: burst pressure / max. operating pressure, min. 4 : 1
Temperature resistance - 40°C ... + 100°C
Operating medium Mineral oil according to DIN 51524
