9.8 Succesive operation of several LUKAS rescue tools
Depending on the rescue situation it might be necessary to employ the pump for a second or third
rescue tool (of course one after another). In such cases observe the following:
Prior to connection of a second tool it must be made sure that the first tool has been fully
closed/retracted ! Of course, the second tool must also be fully closed prior to connection
of a third one and so on. This is necessary for keeping the oil volume of the closed circuit
on the same level throughout the whole operation cycle.
Attention: Do never use the P 600 OB for closing/retracting a rescue tool which has already been
extended with a second pump. Otherwise there is the risk of the diaphragm tank being damaged
by too large oil volume !
9.9 The carry harness
9.9.1 Description
The pump is delivered complete with a carry harness
(item 8, see cover page). The harness consists of a stable
yet extremely light frame with handle, two shoulder straps
with quickadjust mechanism, a adjustable belly girt and a
fixing rail (item 11.2) with arresting lever (item 11.1) The
counter part for accomodation of the fixing rail is mounted
on the housing of the pump by means of two allen screws
(see picture 12, item 12.1).
9.9.2 Individual adjustment of the accommodation rail
The position of the accommodation rail can be individually
adjusted by opening the two allen screws. Set the rail to the most
comfortable position and tighten the screws properly.
It is also possible to mount the accommodation rail on the opposite
side of the pump housing:
remove the two allen screws with plastic disks completely and set the rail to the wanted position.
Place the thinner plastic disk on top of the rail and make sure that harness and pump are aligned
in the vertical position. Tighten the rail with the two allen screws.
9.9.3 Handling of the harness
For fixing the harness on the pump put it in the position as shown on picture 12. Open the arresting
lever (12.3) as far as possible. Push the harness forward until it engages into the accomodation
rail (see picture 13). Depress the arresting lever completely and make sure that the rail is safely
locked.
Hang the unit over your shoulders, use the D-clamps for pushing the shoulder straps forward and
pull them tight (see picture 14). Finally, close the belly girt and pull it tight.
Bild 11
11.1
11.2
