13
15 Technical data
* 1MPa = 10 bar
1 Necessary oil quantity in the hydraulic power pack for operating the tool
(Difference in quantity piston / rode side)
Type LSP 40 B LSP 40 EN LSP 60 EN LSP 60 F
Ref. no. 84150/0890 84150/0895 84150/0547 84150/0560
Spreading force (kN)
in all operating ranges
40 ... 120 41.5 ... 230 62 ... 230 62 ... 230
Spreading distance min. (mm) 620 720 800 800
Pulling force (kN) 28 ... 61 26 ... 46 39...58 w. KSV 1145...65 w. KSV 13
Pulling distance (mm)
with chain set KSV 11
487 575 665 --
with chain set KSV 13 -- -- -- 668
with chain set KSS 20 520 -- 710 710
Dimensions l x w x h (mm) 774x299x170 790x299x180 880x378x212 880x378x212
Weight incl. oil filling (kg) 18 19.6 25 25.8
Operating pressure (MPa) max. 63*
Necessary oil quantity (l) 1 0.13 0.25 0.42 0.34
TÜV (DIN) SP29-93-TP18 SP42-99-TP18 SP43-99-TP18 --
French Standard NFS 61571 120.33.93: EH40-40 EH 60-60
prEN 13204 LHS 40 MHS 60 --
Type LSP 80 EN
Ref. no. 84150/0570
Spreading force (kN)
in all operating ranges
84 ... 540
Spreading distance min. (mm) 610
Pulling force max. (kN) 99
Pulling distance (mm)
with chain set KSV 13/100
437
Dimensions l x w x h (mm) 770x380x216
Weight incl. oil filling (kg) 25.9
Operating pressure (MPa) max. 63*
Necessary oil quantity (l) 1 0.34
TÜV (DIN)
French Standard NFS 61571
EN 13204
CS84/610-26
