12
5. Connecting the equipment
The equipment is connected to the hydraulic pump via mono-coupling halves (male and
female).
5.1 General information
There are two short hoses on the side of the equipment: they are connected to the pump unit
via two hoses. All hose assemblies are marked with a colour and have couplings to enable
unmistakable connection.
5.2 Coupling the mono-couplings
dust protection caps
REMARK:
The devices can be equipped with different coupling systems.
They differ only by the article number and not by the designation.
Of course the coupling systems can also be reequipped at a later time.
WARNING / CAUTION!
Before connecting the equipment you have to pay attention that all
used components are suitable to the max operation pressure of
the pump unit! In the case of doubt you have to inquire LUKAS
directly!
mono-coupling
halve (male) mono-coupling
halve (female)
