Chapter 2 Installing or Replacing Components 33
Adding Memory
The Xserve has 8 memory slots. The systems come with at least 1 gigabyte (GB) of
memory on two fully buffered dual inline memory modules using Error-Correcting
Code (800 MHz DDR2 ECC FB-DIMMs). To improve performance and capacity, you can
install additional DIMMs for a total of up to 32 GB of memory.
The 8 memory slots are labelled DIMM 1 through DIMM 8.
1 2 3 4
5 6 7 8
(Back)
(Front)
