Bowflex.Xceed ™ .Plus.Assembly.Manual
Step 10 ..Leg.Extension.Assembly
parts:
. •...Leg.Extension.Backbone
. •...2.Chrome.Tubes
. •...4.Foam.Rollers
. •...4.End.Caps
tool: ..Rubber.Mallet
10-1 ...Insert.Chrome.Tubes.through.
the.upper.hole.and.one.of.
the.lower.holes.in.the.Leg.
Extension ..(Select.hole.for.
your.comfort.level .)
10-2 ...Slide.Foam.Rollers.onto.the.
Chrome.Tubes.and.secure.
with.end.caps ..A.rubber.
mallet.may.be.needed.to.
secure.the.end.caps .
note: ...The.Leg.Extension.may.be.adjusted..
during.workout.to.best.suit.your.height..
and.personal.preferences .
Step 9 ..Seat.Assembly
parts:
.. •...Seat.Backbone
. •...Seat.Bottom
Hardware:
.•...4.Button.Head.Screws.(5/16".X.3/4")
•...4.Washers.(5/16")
tool: 3/16".Hex.Wrench
9-1 ...Install.the.Seat.Backbone.to.the..
underside.of.the.Seat.Pad.using.
screws.and.washers.as.shown .
Button.Head.
Screws
Flat.Washers
Seat.Backbone
Seat.Bottom
Assembly Guide
Leg.Extension.
Backbone
End.Caps
Foam.Rollers
Chrome.Tubes
Lock.Pin
