Bowflex.Xceed ™ .Plus.Assembly.Manual
Assembly Guide
Step 3
... Install.Lower.Lat.Tower.Assembly
parts:
. •...Lower.Lat.Tower.Assembly.
. •...Base.Frame.Assembly.
Hardware:
•..2.Button.Head.Screws.(3/8".X.3/4")
•..2.Flat.Washers.(3/8")
tool: 7/32”.Hex.Wrench
3-1 ...Align.the.Lower.Lat.Tower.Assembly.over..
the.Base.Frame ..Push.the.bottom.of.the.Lower.
Lat.Tower.onto.the.connector.of.the.Rear.Cross.
Member.as.shown .
3-2 ....Secure.Lower.Lat.Tower.Assembly..
using.screws.and.washers.as.shown ..
Finger tighten screws at this time.
Step 4 Install..Seat.Support.Rail
parts:
. •...Seat.Support.Rail
. •...Base.Frame.Assembly
Hardware:
.•...2.Button.Head.Screws.(3/8".X.3/4")
•...2.Flat.Washers.(3/8")
tool: 7/32".Hex.Wrench
4-1 ...Slide.the.bottom.of.the.Seat.Support.
Rail.onto.the.Base.Frame.connector.
as.shown .
4-2 .....Slide.the.top.of.the.Seat.Support.
Rail.onto.the.Lower.Lat.Tower.
Assembly.connector.as.shown ..
Secure.using.screws.and.washers..
as.shown ..
Finger tighten screws at this time.
Base.Frame.
Assembly
Button.
Head.
Screw
Flat.
Washer
Button.
Head.
Screw
Flat.
Washer
Base.Frame/..
Lower.Lat.Tower
Assembly
Seat.Support.Rail
Flat.
Washer
Button.
Head.
Screw
Button.
Head.
Screw
Flat.
Washer
Lower.Lat.Tower
Assembly
