GFB Deceptor Pro II (part T9507) - Manual (Page 3)

2) Remove the two hoses from in front of
the diverter to gain access to the clamps
behind.
Remove the vacuum hose from the top of the
diverter valve.
Loosen the two hose clamps that retain the
diverter valve.
4) Remove the diverter vacuum hose from
the car and replace with the hose supplied
with the GFB Respons TMS kit.
5) Install the Deceptor Pro II valve, then
re-connect the vacuum hose, the two hoses
in front of the valve, and the turbo intake pipe,
making sure to replace and tighten all bolts
and hose clamps. Connect the cable to the
control box extension loom and make sure to
bundle excess cable securely.
INSTALLING THE VALVE
Note that installing the Respons T9007 must be done from underneath the car, which requires
raising the car on ramps or axle supports, or a hoist.
WARNING: NEVER work under a car supported only with a jack.
1) Remove the plastic section of the under tray by popping the plastic clips and the two bolts.
Note that there are more plastic clips than indicated by the arrows.
Diverter valve location
3) Using a 10mm socket, remove the two
bolts that hold the turbo intake pipe onto the
turbo.
Pull down on the pipe and push up on the
diverter valve simultaneously to pop it out of the
intake pipe. Then pull the diverter valve out of
the vertical charge pipe and set aside.
