PureFlow AirDog DF-165 - 6.0L Ford 2003-2007 - Manual (Page 13)

13
PureFlow AirDog
AirDog
®
II Demand Flow Ford PowerStroke 2003-2007 6.0L
Section 5-B Fuel Lines
Installing the AirDog
® II Air/Vapor Return Line Cont’d
5B-6 Attach the other end of the “Return T Assembly” onto the male end form of the
“Return T” installed in step 5B-2. A ”click” will be heard when the fitting is properly
connected.
Figure 20 Figure 21
5B-7 Any excess fuel hose can be addressed by routing the hose in a fashion to take up
the extra length, or a section of the hose can be removed. Push lock splices have
been included if you choose to remove the excess hose.
