IMPORTANT INFORMATION.
GENERAL CARE AND MAINTENANCE
By choosing ARB vehicle protection, you have bought a product that is one of the most sought after
4WD products in the world. Your under vehicle protection panels are a properly engineered, reliable,
quality accessory that represents excellent value.
 While these panels have been engineered for strength and functionality care and good judgment
should be taken when traversing difficult off-road conditions to minimise damage to panels and
vehicle.
 During servicing when panels are removed ensure fasteners are re-fitted to the correct torque
values.
 Inspect panels visually on a regular basis. Dirt and foreign matter should be washed out to minimise
build-up around hot components. BE VERY CAREFULL when removing foreign matter with hands
while vehicle is hot or running. Replace any components as necessary. This service can be
performed by your local authorized ARB Stockist.
FITTING REQUIREMENTS
REQUIRED TOOLS FOR FITMENT OF PRODUCT:
BASIC TOOL KIT
INC 3/8 DRIVE SOCKET SET
HAVE AVAILABLE THESE SAFETY ITEMS WHEN FITTING PRODUCT :
Protective eyewear Hearing protection
NOTE: ‘WARNING’ notes in the fitting procedure relate to OHS situations, where to avoid a
potentially hazardous situation it is suggested that protective safety gear be worn or a safe work
procedure be employed. If these notes and warnings are not heeded, injury may result.
FASTENER TORQUE SETTINGS:
SIZE Torque Nm Torque lbft
M6 9Nm 7lbft
M8 22Nm 16lbft
M10 44Nm 32lbft
M12 77Nm 57lbft
