06-01-2005 Page 2 of 7 3782877
USE PART No QTY DESCRIPTION
CHASSIS BRACKETS 6151232 4 BOLT M10 x 1.5 x 30mm
TO CHASSIS RAILS 4581048 4 WASHER SPRING M10
4581040 8 WASHER FLAT M10
6151026 4 NUT M10 x 1.5mm
3756224L 1 CHASSIS BRACKET ASSY
3756224R 1 CHASSIS BRACKET ASSY
SPLASH PAN 6151021 2 BOLT M8 x 20mm
TO BULL BAR 4581044 2 WASHER FLAT M8
3314413 1 SPLASH PAN
6151132 2 NUT FLANGE
BULL BAR TO 6151045 6 BOLT M10 x 25mm
CHASSIS BRACKETS 4581048 6 WASHER SPRING M10
4581040 6 WASHER FLAT M10
CONTROL BOX BRACKET 6151021 2 BOLT M8 x 20mm
4581044 2 WASHER FLAT M8
6151132 2 NUT FLANGE M8
3751564 1 BRACKET CONTROL BOX
NUMBER PLATE BRACKET 6151017 4 BOLT M6 x 16mm
6151035 4 WASHER FLAT M6
6151128 4 NUT FLANGE M6
3751313 1 NUMBER PLATE BRACKET
BUFFERS AND TURN SIGNALS 3500170 1 BUFFERS KIT
3500080 1 ARB TURN SIGNALS
8-9000lb WINCH TO PAN 4581040 4 WASHER FLAT 3/8”x 1”
180302 6 CABLE TIES
TOOLS REQUIRED
1 BASIC TOOL KIT, DRILL.
