Fitting instructions# 3786376

GENERAL CARE AND MAINTENANCE

By choosing an ARB Bar, you ha ve bought a product that is one of the most sought after 4WD products

in the world. Your bar is a properly engineered, reliable, quality accessory that represents excellent

value. To keep your bar in original condition it is important to care and maintain it following these

recommendations.

•

Prior to exposure to the weather your bar should be treated to a Canuba based polish on all exposed

surfaces. It is recommended that this is performed on a six monthly basis or following exposure to

salt, mud, sand or other contaminants.

•

As part of any Pre Trip Preparation, or on an annual basis, it is recommended that a thorough visual

inspection of the bar is carried out, making sure that all bolts and other components are torqued to the

correct specification. Also check that all wiring sheaths, connectors, and fittings are free of damage.

Replace any components as necessary.

•

Please contact local Authorised ARB Stockist if you would like to have this service carried out on

your behalf.

HAVE AVAILABLE THESE SAFETY ITEMS WHEN FITTING PRODUCT:

BASIC TOOL KIT

Protective eyewear

Hearing protection

NOTE: ‘WARNING’ notes in the fitting procedure relate to OHS situations, where to avoid a potentially

hazardous situation it is suggested that protective safety gear be worn or a safe work procedure be employed. If

these notes and warnings are not heeded, injury may result.

FASTENER TORQUE SETTINGS:

SIZE

Torque Nm

Torque lbft

9Nm

4lbft

22Nm

16lbft

M10

44Nm

32lbft

M12

77Nm

57lbft

OPTIONAL LIGHT SETS TO SUIT THIS PRODUCT:

Up to IPF 900 SERIES FOG OR DRIVING LIGHT SETS

WARN WINCHES TO FIT THIS PRODUCT

MID SIZE FRAME 6000LB – 9500LB

TI SERIES 9500LB

POWER PLANT 9500LB – 12000LB

RC SERIES 9000LB
