29/8/05 Page 5 of 12 3783172
11. Using 10mm drill bit, drill out holes in
centre of slots in front of cross member.
12. Once holes have been drilled, fit captive nut
channels through lower aperture in vehicle
cross member.
13. Secure using 10mm hardware and tighten
firmly making sure mounting system is hard
against vehicle cross member.
NB. When step 14 is finished, slacken off
bolt tension to enable sideways movement if
needed when bar is fitted.
