GENERAL CARE AND MAINTENANCE

choosing an ARB Bar, you have bought a product that is one of the most sought after 4WD products in

the world. Your bar is a properly engineered, reliable, quality accessory that represents excellent value.
To keep your bar in original condition it is important to care and maintain it following these
recommendations:

Prior to exposure to the weather your bar should be treated to a Canuba based polish on all exposed

surfaces. It is recommended that this is performed on a six monthly basis or following exposure to
salt, mud, sand or other contaminants.

As part of any Pre Trip Preparation, or on an annual basis, it is recommended that a thorough visual

inspection of the bar is carried out, making sure that all bolts and other components are torqued to the
correct specification. Also check that all wiring sheaths, connectors, and fittings are free of damage.
Replace any components as necessary. This service can be performed by your local authorised ARB
stockist.

FITTING REQUIREMENTS

REQUIRED TOOLS FOR FITMENT OF PRODUCT:

Metric socket and spanner sets 8-25mm range

External Circlip pliers

Screwdrivers Philips and Flat blade

Cold chisel

Hammer

Power Drill 13mm capacity

10mm and 13mm drill bits

HAVE AVAILABLE THESE SAFETY ITEMS WHEN FITTING PRODUCT

Protective eyewear

Hearing protection

NOTE: ‘WARNING’ notes in the fitting procedure relate to OHS situations, where to avoid a
potentially hazardous situation it is suggested that protective safety gear be worn or a safe work
procedure be employed. If these notes and warnings are not heeded, injury may result.

FASTENER TORQUE SETTINGS:

SIZE

Torque Nm

Torque lbft

9Nm

4lbft

22Nm

16lbft

M10

44Nm

32lbft

M12

77Nm

57lbft

OPTIONAL LIGHT SETS TO SUIT THIS PRODUCT:

i ARB 6821201 FOG LAMP SUIT 3163015
i Up to IPF 900 SERIES FOG OR DRIVING LIGHT SETS
