Philips BDH5011-74B - Manual (Page 51)

Y/PB/PR For Component 1 and 2
Mode Resolution Rate
1 640 x 480p 60
2 1920 x1080i 60
3 1280 x 720p 60
Maximum Resolution: Up to 1280 x 1024 (VGA Mode)
Dimensions: Without/Stand With/Stand
Width: 1256 mm 1256 mm
Height: 762 mm 810 mm
Depth: 107.5 mm 300 mm
Package Dimensions
Width: 1436 mm
Height: 1125 mm
Depth: 470 mm
Weight
Net weight: 108.00 lbs/49 kgs (w/ stand)
Gross weight: 132.24 lbs/60 kgs
Operating
Temperature: 0~40 Degrees C (32~104 degrees F)
Relative humidity: 20~80%
Pressure: 800~1100hpa
Non-Operating
Temperature: - 20~60 Degrees C (-4~140 Degrees F)
Relative humidity: 00~90%
Pressure: 700~1100hpa
Vibration: X/Y/Z, 0.5G/10~55Hz (sweep), 10 minutes
Acoustics
(IHF A-weighted 1meter): 40dB Max.
Sound
Residual hum (at volume max): 500µW Max.
Practical max. Audio output (at 10% THD max.): 1.0vp-p 1K Hz
input 5W +5W
Max. /12 ohm
Sound distortion (at 250 mw 1K Hz): 1% Max.
Audio output (input at 1.4V p-p ): >=1.0 V P-P
Reliability Requirement
The MTBF is 20,000 hrs under operation 25±5 Degrees C
(Half luminosity, motion picture).
51
User Manual BDH5011
