5. Connections
5.3 Signal connections
Overview
• The input section
• Connecting a Composite video signal
• Connecting an S-Video signal
• Connecting an RGB signal
• Connecting a Component Video signal
• Connecting a DVI signal
• Connecting a computer signal
• The DVI output
5.3.1 The input section
Input layers
The input section is located at the front of the projector and is composed of 3 layers which can be equipped with different input
modules depending on the ordered options .
The standard layers :
• Layer 1: DVI Input/Output module:
• Layer 2: RGBHV & Video analog input module
• Layer 3: DVI & Computer (D15) input module
• Layer 4 : Single Board Computer connections
The different available options :
• One extra RGBHV & Video analog input module on Layer 3
• HD SDI/SDI input output input module on Layer 3
Image 5-5
R5976992 ICON H250/400 13/12/2006 21
