24
NOTE: With the help of a friend, turn
the cart to its upright position.
Step 4
Install door bracket using four
M6 X 50mm bolts and two M6 X 15
mm bolts.
Step 5
Attach the grease cup bracket onto
the back panel by inserting the
three tabs into the slots on the back
cart panel.
NOTE: When performing Step 6,
Lift grill body from front and
rear panels to avoid injury to
hands and fingers.
Step 6
With the help of a friend, place grill
body assembly on cart frame. Grill
body will rest on the side bars of
cart frame assembly. Align bolt
holes located on the outside of the
grill body assembly.
