ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR GRILL.
WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT.
The following provided tools are required to assemble this ProSeries 4655 Stainless Steel Gas
Grill:
• Flathead Screwdriver
• Hex Nut Wrench
1 Electronic Igniter Spring
1 Right Side Cart Panel
1 Side Burner Front Panel
1 Side Burner Knob
1 Bezel
2 Door Handles
1 Grease Tray
1 Back Panel
1 Cart Base
2 Doors
1 Basket
2 Basket Brackets
4 Locking Casters
2 Door Brackets
1 Basket Guide
1 Loop Strap Bracket
PARTS LIST:
1 Grill Body Assembly
6 Burners
6 Control Knobs
1 Warming Rack
1 Grease Cup
1 Grease Cup Bracket
3 Cooking Grills
1 Side Burner Grate
1 Left Side Table
6 Heat Distribution Plates
1 Side Burner Assembly
1 Left Side Table Front Panel
1 Door Bracket
1 Left Side Cart Panel
1 Electronic Igniter Button
1
2
3
4
5
6
7
8
9
10
11
12
13
14
16
17
18
19
20
21
22
23
24
25
15
26
27
28
29
30
31
