8. COVERS PR2001050
REF.NO. CODE Q'TY DESCRIPTION REMARK
1 UH2065001 1 UPPER COVER ASSY, GRAY1227
2 UH2071001 1 TONER CARTRIDGE LID, GRAY1227
3 UH2072001 1 FONT COVER ASSY, GRAY1227
4 UH2076001 1 CLEANER BRUSH
5 UH2077001 1 SIDE COVER L, GRAY1227
6 UH2027001 1 SIDE COVER R2 ASSY, GRAY1227
7-8 UH2082001 1 REAR COVER ASSY, GRAY1227(HL-1660)
7-8 UH2104001 1 REAR COVER ASSY, GRAY1227(TMT-17)
7 UH2085001 1 CHANGEOVER GUIDE, GRAY1227
8 UH2103001 1 JAM REMOVE COVER, GRAY1227
9 087320616 2 TAPTITE, CUP S M3X6
10 087320616 1 TAPTITE, CUP S M3X6
11 087320616 1 TAPTITE, CUP S M3X6
12 087321016 2 TAPTITE, CUP S M3X10
MODEL HL-1660/TMT-17 54T-U01-400
T/I NO. PR98175 / PR99088
9. CHASSIS
REF.NO. CODE Q'TY DESCRIPTION REMARK
1 UH2229001 1 CARTRIDGE STOPPER ASSY
2 UH2233001 1 DC GEAR HOLDER ASSY
3 UH2814001 1 DC MOTOR ASSY 2 (SP)
4 087320616 3 TAPTITE, CUP S M3X6
5 UH2238000 1 GEAR 39
6 UH2239000 1 GEAR 20/50
7 UH2240000 1 GEAR 24/72
8 UH2241000 1 GEAR 22/55
9 UH2242000 1 GEAR 48
10 UH2243000 1 GEAR 21
11 UH2244000 1 GEAR 28
12 UH2245001 1 GEAR 48 SPRING
13 026100136 1 WASHER, PLAIN S 10
14 UH2255001 1 PAPER DELIVERY GEAR ASSY
15 U74234001 4 TAPTITE, CUP M4X5
16 UH2250001 1 PAPER DELIVERY HOLDER SPRING
17 UH2252000 1 SPACER 2
18 UH2254000 2 SPACER 1
19 T31242001 2 PCB SPACER F
20 UH2263001 1 SCANNER FAN MOTOR
21 083313015 2 TAPTITE, PAN B M3X30
22 087320616 1 TAPTITE, CUP S M3X6
23 UH2209000 2 TRAY GUIDE
MODEL HL-1660/TMT-17 54T-U02-500
T/I NO. PR2001050
