Connecting to Propane Gas
Position the cylinder in the opening in the bottom of
the cart and secure with the cylinder retaining
bracket. F
IGURE
20.
Attach the pressure regulator to the Propane
gas cylinder’s valve using the plastic handwheel.
Tighten in a clockwise motion to achieve a gas
tight seal. F
IGURE
21.
C
AUTION
: D
O
NOT
USE
A
WRENCH
OR
ANY
OTHER
TOOL
TO
TIGHTEN
. U
SE
OF
A
WRENCH
OR
OTHER
TOOL
WILL
DAMAGE
THE
PLASTIC
HANDWHEEL
.
To disconnect the Propane gas cylinder, turn
OFF the cylinder’s valve and the grill’s control
valve. Remove the regulator by turning the
plastic handwheel counterclockwise.
The pressure regulator has an outlet pressure of
not more than eleven (11”) inches water column.
It must be connected to the Propane gas
cylinder’s female valve outlet before the grill can
be operated.
C
AUTION
: O
PERATION
OF
A
P
ROPANE
GAS
GRILL
WITHOUT
THE
PRESSURE
REGULATOR
AND
HOSE
ASSEMBLY
WILL
CAUSE
GAS
LEAKS
WHICH
COULD
LEAD
TO
FIRE
OR
EXPLOSION
,
RESULTING
IN
PROPERTY
DAMAGE
OR
PERSONAL
INJURY
.
The pressure regulator’s fitting must remain
clean and free of nicks and scratches. A dirty,
nicked or scratched fitting can cause a gas leak,
resulting in an explosion or fire. Use only
genuine Broilmaster
®
replacement parts unless
otherwise specified by the manufacturer.
Pressure Regulator and
Hose Assembly
Connecting to Propane Gas
(Continued)
Cylinder
Retaining
Bracket
F
IGURE
20
F
IGURE
21
