Philips Seismic Edge
 
14
LINE IN:
Connect from any external sound source such as
external CD-ROM, cassette, CD player, etc.
MICROPHONE JACK:
Connect to external microphone.
FRONT OUT:
Connect a set of powered speakers or stereo
headphones to the FRONT OUT speaker jack.
REAR OUT (optional):
Connect a pair of powered speakers to REAR
OUT speaker jack.
MIDI/GAME PORT:
Connect Joystick or MIDI device.
8. Connect your audio devices to the panel of your sound card as
indicated below:
9. Replace computer cover and reconnect the power cable, moni-
tor, and other devices.
