Manual No. 7006258 22" STEEL DECK WALK BEHIND MOWERS
9
Deck Assembly (Push)
Part No Description Item Qty
1 7300401D 1 DECK, 22” Walk
2 7900067 3 SCREW, 1/4-20 x 11/16” Pan Head Self-Tap (Torx) or 722848
3 7091020 4 PUSHNUT, 1/4”
4 7300855D 1 BRACKET, Chute
5 7300856D 1 PLATE, Mulch, 22” RB Scott's
6 722507 1 SPRING, Chute (Torsion)
7 7101067 1 ROD, Pivot (1/4” Dia. x 5.55”)
8 721682 1 COVER, Mulch, Plastic, Black
9 721681 1 SIDE CHUTE, Plastic, Black
10 7103347 1 GUARD, Rear
11 7091286 4 SCREW, #10-24 x 1/2” Hex Washer Self-Tap (Sems)
12 7091619 4 NUT, 3/8-16 Hex Flange Lock, YZ
13 7501055 1 * ASSY, Height-Of-Cut, Left Rear, 22” WBM, Push & Propelled
14 7501056 1 * ASSY, Height-Of-Cut, Right Rear, 22” WBM, Push & Propelled
15 7501294 1 * ASSY, Height-Of-Cut, Left Front, 22” WBM, Push
16 7501293 1 * ASSY, Height-Of-Cut, Right Front, 22” WBM, Push
17 7100633 4 GRIP, Height Latch
18 7500540 4 ASSY, Wheel & Bearing, 8 x 2 Idle, DW Tread incl. two 1-1/8” O.D. Flanged Ball Bearings (p/n
7101380)
19 7300440D 1 BAFFLE, Front, 22” WBM
20 722604 4 WASHER, 1” O.D. x .387 I.D. Flat
21 7091585 4 NUT, 3/8-16 Hex Center Lock, YZ
22 7101350 4 HUBCAP, Black
23 7300854D 1 BAFFLE, Rear, 22” Deck or 725105
24 7101243 1 DOOR, 22” Rear
25 7101070 1 ROD, Pivot, Rear Door (1/4” Dia. X 17-1/2”)
26 7101461 1 SPRING, Torsion, Rear Door, 22” WBM
27 7300668BH 1 BRACKET, Lower Handle, RH, 22” WBM
28 7300669BH 1 BRACKET, Lower Handle, LH, 22” WBM
29 7091318 2 BOLT, 5/16-18 x 3/4” Hex Head Cap, GR5
30 7091601 2 NUT, 5/16-18 Flange Lock, YZ
Note: * This assembly is also shown on Height-of-Cut Assemblies page.
