Manual No.
7006258
22" STEEL DECK WALK BEHIND MOWERS
7
Handles & Controls (Self-Propelled)
Part No
Description
Item
Qty
1
7101312
1
UPPER HANDLE, Plastic, WBM
2
7101417
1
ASSY, Control Head, 22” WBM, Single Speed (incl.Clutch Lever, Box, & Drive Cable)
3
7101321BH
1
BAIL, Plastic Handle, WBM
4
7090015
2
BOLT, 1/4-20 x 1-3/4” Round Head Square Neck, GR 2, YZ
5
2860694
3
NUT, 1/4-20, Hex Flange (Nyloc) YZ
6
7300670A
1
PLATE, Control Panel
7
95050
4
SCREW, #8-16 x 5/8” Recessed Pan Head Twin Helix (Torx) or 7100225
8
7300649BH
2
HANDLE, Connecting, 21”/22” WBM
9
7101410
1
GUIDE, Rope (1/4-20 thread)
10
7035744
2
KNOB, 5/16-18 Wing (5/16-18 thread) (Black)
11
7091189
2
BOLT, 5/16-18 x 2” Curved Head Square Neck, GR 2
12
7090391
2
WASHER, 5/16” Internal Tooth Lock
13
7300628BH
1
HANDLE, Lower, 22” WBM
14
7101395
1
CABLE, Bail, 22” WBM
15
7101202
2
KNOB, Quick Release
16
7101199
2
BUSHING, Handle Pin
17
7101200
2
SPRING, Compression
18
7101198
2
PIN, Handle Adjust
19
7090958
2
BOLT, 5/16-18 x 1-1/2” Round Head Short Square Neck, GR 5 or 7091303
20
7090951
2
NUT, 5/16-18 Large Flange Center Lock
21
7102573
1
GRASS BAG, 22” Rear Discharge or 7101246
22
7101230A
1
BAG FRAME, 22” WBM (Weldment)
23
7026421
1
GRIP, Rectangular (Black)
24
7024649
3
WIRE TIE, 11” Standard Black Nylon
