22" STEEL DECK WALK BEHIND MOWERS
11
Deck Assemby (Self-Propelled)
Part No
Description
Item
Qty
1
7300400D
1
DECK, 22” Walk, 3 N 1
2
7900067
3
SCREW, 1/4-20 x 11/16” Pan Head Self-Tap (Torx) or 722848
3
7091020
4
PUSHNUT 1/4”
4
7300855D
1
BRACKET, Chute or 726768
5
7300856D
1
PLATE, Mulch, 22” RB Scott's or 726766
6
722507
1
SPRING, Chute (Torsion)
7
7101067
1
ROD, Pivot (1/4” Dia. x 5.55”)
8
721682
1
COVER, Mulch, Plastic, Black
9
721681
1
SIDE CHUTE, Plastic, Black
10
7103347
1
GUARD, Rear or 721685
11
7091286
4
SCREW, #10-24 x 1/2” Hex Washer Self-Tap (Sems)
12
7091619
10
NUT, 3/8-16 Hex Flange Lock, YZ
13
7501055
1
* ASSY, Height-Of-Cut, Left Rear, 22” WBM
14
7501056
1
* ASSY, Height-Of-Cut, Right Rear, 22” WBM
15
7501058
1
* ASSY, Height-Of-Cut, LF, 22” WBM, Propelled
16
7501057
1
* ASSY, Height-Of-Cut, RF, 22” WBM, Propelled
17
7100633
4
GRIP, Height Latch
18
7500540
2
ASSY, Wheel & Bearing, 8 x 2 Idle, DW Tread incl. two 1-1/8” O.D. Flanged Ball Bearings (p/n
7101380)
19
7500542
2
ASSY, Drive Wheel & Bearing, 8 x 2, DW Tread incl. two 1-1/8” O.D. Flanged Ball Bearings (p/n
7101380)
20
722604
4
WASHER, 1” O.D. x .387 I.D. Flat
21
7091585
4
NUT, 3/8-16 Hex Center Lock, YZ
22
7101350
4
HUBCAP, Black
23
7102671
1
SPACER, .526" ID, .840" OD, .502" Wide (Was 720508)
24
7101243
1
DOOR, 22” Rear
25
7101070
1
ROD, Pivot, Rear Door (1/4” Dia. X 17-1/2”)
26
7101461
1
SPRING, Torsion, Rear Door, 22” WBM
27
7300668BH
1
BRACKET, Lower Handle, RH, 22” WBM
28
7300669BH
1
BRACKET, Lower Handle, LH, 22” WBM
29
7091811
2
BOLT, 5/16-18 x 5/8” Hex Flange Lock, YZ
30
7091601
3
NUT, 5/16-18 Flange Lock, YZ
31
7014341
4
RING, External Retaining (Waldes 5133-50)
32
7101207
2
GEAR, Pinion, 22” WBM, Front Wheel Drive
33
7101402
2
DUST SHIELD, Forward, 22” WBM
34
7900054
4
SCREW, 3/8-16 x 3/4” Hex Head Cap, GR 5, YZ
35
7101206
1
TRANSMISSION, 22” WBM Single Speed, Front Wheel Drive used on SP2265 & NSP22656
36
7101270
2
DRIVE PIN, 22” WBM, Front Wheel Drive
37
7300854D
1
BAFFLE, Rear, 22” Deck or 725105
38
7300440D
1
BAFFLE, Front, 22” WBM
39
722410
1
SPRING, Compression
Note: * This assembly is also shown on Height-of-Cut Assemblies page.
