Manual No.
7006258
22" STEEL DECK WALK BEHIND MOWERS
5
Handles & Controls (Push)
Part No
Description
Item
Qty
1
7101405
1
UPPER HANDLE, Plastic, Snapper Push
2
7101321BH
1
BAIL, Plastic Handle, WBM
3
7090015
2
BOLT, 1/4-20 x 1-3/4” Round Head Square Neck, GR 2, YZ
4
2860694
3
NUT, 1/4-20, Hex Flange (Esna) YZ
5
7300649BH
2
HANDLE, Connecting, 21”/22” WBM
6
7101410
1
ROPE GUIDE (1/4-20 thread)
7
7035744
2
KNOB, 5/16-18 Wing (5/16-18 thread) (Black)
8
7091189
2
BOLT, 5/16-18 x 2” Curved Head Square Neck, GR 2
9
7090391
2
WASHER, 5/16” Internal Tooth Lock
10
7300628BH
1
HANDLE, Lower, 22” WBM
11
7101395
1
CABLE, Bail, 22” WBM
12
7101202
2
KNOB, Quick Release
13
7101199
2
BUSHING, Handle Pin
14
7101200
2
SPRING, Compression
15
7101198
2
PIN, Handle Adjust
16
7090958
2
BOLT, 5/16-18 x 1-1/2” Round Head Short Square Neck, GR 5 or 7091303
17
7090951
2
NUT, 5/16-18 Large Flange Center Lock
18
7102573
1
GRASS BAG, 22” Rear Discharge replaces 7101246
19
7101230A
1
BAG FRAME, 22” WBM (Weldment)
20
7024649
3
WIRE TIE,11” Standard Black Nylon
21
7026421
1
GRIP, Rectangular (Black)
