Footnotes:
Manual No. 7006258 22" STEEL DECK WALK BEHIND MOWERS
15
Height-of-Cut Assemblies
Part No Description Item Qty
1 7501056 1 * ASSY, Height-Of-Cut, Right Rear, 22” WBM, Push & Propelled
2 7501055 1 * ASSY, Height-Of-Cut, Left Rear, 22” WBM, Push & Propelled
3 7501057 1 * ASSY, Height-Of-Cut, RF, 22” WBM, Propelled
4 7501058 1 * ASSY, Height-Of-Cut, LF, 22” WBM, Propelled
5 7501293 1 * ASSY, Height-Of-Cut, Right Front, 22” WBM, Push
6 7501294 1 * ASSY, Height-Of-Cut, Left Front, 22” WBM, Push
7 7091497 1 SCREW, 3/8-16 x 1-1/2” Hex Head Cap, GR 5, YZ
8 7900047 1 WASHER, .391 x 1” x 14 Ga. Flat
9 7900046 1 WASHER, .76 x 1.25 x .180 Flat
10 7101205 1 LEVER, Height-Of-Cut, 22” WBM
11 7500409 1 ASSY, Rear Axle, RH 22” WBM
12 7500408 1 ASSY, Rear Axle, LH 22” WBM
13 722611 1 WASHER, 1” I.D. x 1.64 O.D. Bellville
14 7300529 1 INDEX PLATE, Height-Of-Cut, Rear
15 721899 1 SPACER, Height Adjust
16 7013847 1 RETAINER, 3/8” Bolt
17 720118 1 RING, .906 I.D. x .078 Thick, External Retaining
18 7500404 1 ASSY, Front Axle 22”, Propelled
19 7101212 1 LEVER, Height-Of-Cut, 22” WBM
20 7300528 1 INDEX PLATE, Height-Of-Cut, Front Right, 22” WBM
21 7300527 1 INDEX PLATE, Height-Of-Cut, Front Left, 22” WBM
22 720685 1 RETAINER, Bearing
23 720761 1 BALL BEARING, 1/2 I.D. x 1-1/8” O. D. Flanged w/seal
24 7500476 1 ASSY, Front Axle, 22” WBM, Push
Note: * This assembly is also shown on Deck Assemby page.
