PC Card Specifications
A-2
Radio Specifications
Table A.2 – Radio Specifications
Item Specification Description
Radio Type Direct Sequence 2.4 GHz ISM Band
Operating
Frequency 2400-2497 North American, ETSI, and
Japan channel coverage,
factory configurable
FCC ID LOZ102034 (4500) FCC approval
LOZ102035 (4800)
Channeling 5 MHz increments Programmable for IEEE 802.11
Type of Modulation BPSK 1 Mbit/s (4500)
QPSK 2 Mbit/s Nominal 10 MHz BW (-6 db)
BPSK 1 Mbit/s (4800)
QPSK 2 Mbit/s
CCK 5.5 and 11 Mbits/s
Power Output
(North American
Configuration) 100 mW Meets FCC Part 15.247
requirements
Antenna Type Diversity External connection two
antenna jacks (primary and
secondary)
Antenna Connec-
tors 2 Amphenol MicroMate
female Unique connector per FCC
Part 15.203. Snap-On with 1.5-
2.5 lb retension force
Mating Cable
Connectors Huber & Suhner:
Amphenol: MMCX-50 Series
MicroMate Series PCMCIA Connector Card Connector Per PC Card
(Nov 95) Physical
Specification 4.1
