17
Table 7 – Troubleshooting
FAULT DESCRIPTION SENT TO UI
FLASH CODE
(AMBER LED)
RESET TIME
(minutes)
--- --- Standby ON, no flash
--- ---
Variable Capacity or Emergency
Mode
1, pause
--- --- Variable Speed Range Cutback
1 (2 sec ON), longer pause (1
second OFF)
Communications Loss 16 NA
Invalid Model 25 NA
High Pressure Switch Open 31 15
Low Pressure Trip 32 15
Control Fault 45 NA
Brownout 46 Revert to 5 min cycle delay
Lost Inverter Communications 48 Revert to 5 min cycle delay
230VAC Dropout---Reset Event 49 Revert to 5 min cycle delay
Outdoor Air Temp Sensor Fault 53 NA
Suction Temp Sensor Fault 54 15
Coil Temp Sensor Fault 55 NA
OAT---OCT Thermistor Out of range 56 NA
Suction Pressure Sensor Fault 57 15
OAT---OST Thermistor Out of range 58 5
Compressor Scroll Temp Out of Range 59 15
Compressor Sump Heating Active 68 2 HOURS
Inverter / Compressor Internal Fault 69 15
Compressor Motor Temp Out of Range 71 15
Suction Over Temperature 72 15
Inverter Temp Out of Range Event 75 15
Inverter Over Current 77 15
Compressor No---Pump Event 79 15
Suction Over Temp Lockout 82 4 Hours
Low Pressure Lockout for 4 hours 83 4 HOURS
High Pressure Lockout for 4 hours 84 4 HOURS
Compressor Temp Lockout 85 4 HOURS
Compressor Temp Sensor Fault 86 15
Inverter Temp Lockout 88 4 HOURS
Inverter VDC---Out Over Voltage 91 15
Inverter VDC---Out Under Voltage 92 15
230VAC Under Voltage 93 15
230VAC Over Voltage 94 15
High Current Lockout 95 2 HOURS
VDC Under Voltage Lockout 96 2 HOURS
VDC Over Voltage Lockout 97 2 HOURS
High Torque Event 98 10
High Torque Lockout 99 2 HOURS
--- --- OFF NA
