Tools menu – Barco R500 User Manual
Page 90
8. Tools Menu
4. Use ↑ or ↓ to select Diagnostics
5. Press → to pull down the menu
6. Press ENTER to select I
2
A textbox is displayed (image 8-22, image 8-23)
Image 8-21
I
2
C diagnostics
fpga backplane1
fpga backplane2
fpga backplane3
ADC layer1
ADC layer2
ADC layer3
Serial eeprom DVI layer2
Serial eeprom DVI layer3
Video decoder
Video indicator
Video Processor
Motor driver
Lamp driver
Device
Slave address
Image 8-22
Image 8-23
84
R5976694 IQ PRO R500 01/02/2007
