Barco R500 - Manual (Page 157)

15. iQ Network
3. Slide the cursors to set the corresponding value (image 15-38)
Image 15-37
Image 15-38
Use the checkbox to define a coarse or a fine setting.
Click on the Filmmode button to enable or disable the filmmode.
Color temperature preset settings
1. Click on Image settings menu in the tool bar to drop down the submenu.
2. Click on color temp, image 15-37
3. Click on the desired preset color temperature. (image 15-39)
Image 15-39
Custom color temperature setting
1. Click on the Custom button.
A dialog box is displayed. (image 15-40)
2. Use the sliders to set the red and the blue color temperature.
R5976694 IQ PRO R500 01/02/2007 151
