Blodgett KLT-20G - Manual (Page 14)

FIGURE 5
SPRING ASSIST HINGE ASSEMBLY
ITEM Part Number DESCRIPTION QUANTITY
42112 HINGE ASSEMBLY
1 41543 Lock Pin 1
2 41546 End Lock Plate 1
3 43106 Stationary Disc 1
4 41100 Core 1
5 41526 Spring 1
** 6 41538 Handle Assembly (20 Gallon) 1
41539 Handle Assembly (30, 40 Gallon) 1
41531 Handle Assembly (60 Gallon) 1
7 43107 Rotary Disc 1
8 41520 End Stop Plate 1
9 40098 Cap Screws 4
10 40259 Knob 1
** 11 42713 Hinge Support Riser (20, 30, 40 Gal.) 1
42714 Hinge Support Riser (60 Gal.) 1
** 12 40017 Cover, 20 Gallon Kettle 1
41514 Cover, 30-40 Gallon Kettle 1
41515 Cover, 60 Gallon Kettle 1
** SELECT AS REQUIRED.
