Blodgett Electric Tilting Kettle on Legs KLT-E User Manual
Klt-e, Klt-e tri-leg tilting kettle, Electric tilting kettle on legs

Project
Item No.
Quantity
q
Model KLT-20E - 20 gallon (76 litres) electric tri-leg tilting kettle
q
Model KLT-30E - 30 gallon (114 litres) electric tri-leg tilting kettle
q
Model KLT-40E - 40 gallon (151 litres) electric tri-leg tilting kettle
q
Model KLT-60E - 60 gallon (227 litres) electric four leg tilting kettle
q
Model KLT-80E - 80 gallon (303 litres) electric four leg tilting kettle
q
Model KLT-100E - 100 gallon (379 litres) electric four leg tilting kettle
CONSTRUCTION
n
304 stainless steel construction
n
2/3 jacketed with factory sealed distilled water enclosure
n
Hemispherical design on bottom of kettle for superior heat circulation
n
Drip proof stainless steel console
n
Welded 1-5/8” (41mm) diameter stainless steel frame and legs
n
Legs fitted with four hole adjustable flanged feet for securing to floor
n
Self-locking tilt mechanism with trunnions and outbore bearing con-
nected to the frame permit the kettle to tilt forward 90° for emptying
n
Stainless steel control housing
n
316 stainless steel liner on 20, 30 and 40 gallon models
OPERATION
n
Electrically self-generated closed steam system
n
Integrally mounted controls
n
Power switch
n
Thermostat
n
Cook indicator light
n
Pressure gauge
n
Safety valve
n
Low water light
n
Low water shut off
n
165-285°F (74-140°C) temperature range
STANDARD FEATURES
n
Manual control
n
Stainless steel faucet bracket
n
Standard voltage options
q 208 VAC, 3 phase, 60 Hz
q 240 VAC, 3 phase, 60 Hz
q 208 VAC, 1 phase, 60 Hz ( 20 & 30 gallon models only)
q 240 VAC, 1 phase, 60 Hz ( 20 & 30 gallon models only)
n
One year parts and labor warranty*
* For all international markets, contact your local distributor.
BLODGETT
www.blodgett.com
44 Lakeside Avenue, Burlington, VT 05401
Phone: (802) 658-6600 • Fax: (802) 864-0183
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
n
Voltage options
q 220 VAC, 1 phase, 60 Hz (20, 30 & 40 gallon
only)
q 220 VAC, 3 phase, 60 Hz
q 380 VAC, 3 phase, 60 Hz
q 415 VAC, 3 phase, 60 Hz
q 480 VAC, 3 phase, 60 Hz
q 220/380 VAC, 3 phase, 4 wire
q 240/415 VAC, 3 phase, 4 wire
q 600 VAC, 3 phase, 60 hz
n
Power increase options
q 24 kW elements for 40, 60 & 80 gallon
q 33 kW elements for 60, 80 & 100 gallon
n
Faucets
q Single pantry faucet with swing spout
q Double pantry faucet with swing spout
n
Covers
q One piece lift off stainless steel cover
q Spring assist hinged stainless steel cover
n
Draw Off valves and accessories
q 2” (50mm) draw off valve
q 3” (76mm) draw off valve
q 3” (76mm) dairy valve
q Perforated strainer for draw off
q Solid stainless steel disc for draw off valve
n
Etched markings
q Gallons
q Litres
q
Correctional package
q
316 stainless steel liner for 60, 80 & 100 gallon mod-
els
q
Tri-basket assembly
q
Graduated measuring strip
q
Pour strainer
q
Strainer hook
q
Pan support
KLT-E
Electric Tilting Kettle on Legs
KLT-E
TRI-LEG
TILTING
KETTLE
