Blodgett KLT-20G - Manual (Page 11)

FIGURE 4
ITEM Part Number DESCRIPTION 20 30
40 60
** 1 42589 Complete Burner Assembly, Natural Gas 1
42592 Complete Burner Assembly, LP Gas 1
42588 Complete Burner Assembly, Natural Gas 1
42591 Complete Burner Assembly, LP Gas 1
42593 Complete Burner Assembly, Natural Gas 1
42590 Complete Burner Assembly, LP Gas 1
2 40503 DSI Module 1 1 1
3 42450 Ignition Wire 18" 1 1 1
4 41861 Fuse, 250V, 3 Amp. 1 1 1
5 40505 Transformer, 120/24V, 50/60, 30 VA 1 1 1
6 42445 Motor/Blower, 115V/50/60 HZ 1 1 1
7 42595 Control/Ignition Module, Wire Harness 1 1 1
8 42981 Air Shutter Assembly 1 1 1
9 42983 Venturi Assembly 1 1 1
10 42449 Electrode Assembly 1 1 1
11 42984 Electrode Mounting Bracket 1 1 1
12 42986 Adaptor Bushing 7/8" 1 1 1
13 42987 Control Box with Strap 1 1 1
14 42988 Control Box Lid 1 1 1
15 42989 Tube/Housing 6" 1 1 1
16 42990 Flange Gasket 6-1/2" Square 1 1 1
17 42980 Adj. Flange Assembly, 6-1/2" Square 1 1 1
18 41107 Gas Valve (Natural/L.P.) 1 1 1
** 19 42975 Orifice #19, Natural Gas 1
42978 Orifice #30, L.P. Gas 1
42974 Orifice #13, Natural Gas 1
42977 Orifice #27, L.P. Gas 1
42979 Orifice #7, Natural Gas 1
** 19 42976 Orifice #23, L.P. Gas 1
20 42982 Orifice Holder 1 1 1
21 41804 Gas Flex Tube 1 1 1
22 40938 Interlock Switch 1 1 1
