Instruction 4-9415
Bacharach, Inc.
Flue Gas Sample Conditioning System
Figure 2. Equipment Setup
PELTIER
COOLER
PROBE ASSEMBLY
PUMP
POWER SUPPLY
100 – 240 VAC
50/60 HZ
Connect to
Combustion Test
Equipment
STACK TEMP.
THERMOCOUPLE
PRESSURE (Blue)
FLUE GAS (Yellow)
