Broilmaster PCB1-2 - Manual (Page 7)

B101586-4-0112 Page 7
C
Art
h
ArdwArE
p
ACkAgE
PHILLIPS TRUSS HEAD SCREW 1/4-20 X 3/4
1/4 ID X 5/8 OD FLAT WASHER
1/4-20 HEX NUT
HEX HEAD BOLT 1/4-20 X 3/4
1/4 ID X 1/2 OD LOCK WASHER
PHILLIPS SCREW 10-24 X 1/2
10-24 KEPS NUT
1/4-20 WING NUT
½ SNAP BUSHING
PHILLIPS TRUSS HEAD SCREW 1/4-20 X 1 1/4
Note: Hardware shown at actual size where possible.
Description Qty
Supplied
Description Qty
Supplied
PHILLIPS TRUSS HEAD SCREW 1/4-20 X 3/4 8 10-24 KEPS NUT 6
HEX HEAD BOLT 1/4-20 X 3/4 4 1/4-20 WING NUT 1
1/4-20 HEX NUT 4 1/2 SNAP BUSHING 1
1/4 ID X 1/2 OD LOCK WASHER 1 PHILLIPS TRUSS HEAD SCREW 1/4-20 X 1 1/4 1
PHILLIPS SCREW 10-24 X 1/2 6 1/4 ID X 5/8 OD FLAT WASHER 4
