SET PULSE BREW:
This function allows the operator to program
the brewer to "pulse” the sprayhead flow on and off
during a brew cycle (start and stop the flow of water
out of the sprayhead). This feature allows the ability
to “fine-tune” the brewer for specific flavor profiles.
Pulse brewing can be set up for any and all batches.
a) 1st ON TIME - This time is the duration from when
the BREW switch is pressed to when the desired
water level in the funnel is reached. (Soaking the
grounds)
b) OFF-TIME - This time is the duration from when
the water in the funnel reaches the desired ON
TIME level to when it drains out of the funnel to a
desired lower level.
c) LAST ON-TIME- This time is the duration from when
the water in the funnel drains down to the lower
level to when it fills the funnel to a desired higher
level. (Soaking the grounds).
These three times can be set two different ways.
The first is accomplished by utilizing the EASY PULSE
screen and following the subsequent steps under that
function.
The other allows the actual times to be entered
for each of the settings. This is done by utilizing the
ENTER TIMES screen and following the subsequent
steps under that function.
Either of these methods can be used to set the
pulse brew for each batch.
P2293
PROGRAMMING THE BREWER (cont.)
INITIAL SPRAY
INITIAL SPRAY
ALTERNATES UNTIL
BREW CYCLE IS
COMPLETED
PRE-INFUSION
REMAINING ON
ON-
TIME
OFF-
TIME
OFF-TIME
OFF-
TIME
OFF-
TIME
ON-
TIME
ON-
TIME
Modifying pulse brew:
Range: 1st on time - off to 4 minutes
Off time - off to 4 minutes
Last on time - Preinfusion to 4 minutes
NOTE: If the brewer is already in the SET PULSE BREW
screen, it is not necessary to follow steps 1 through 8
in this section, but proceed directly to step 9.
1. Press and hold the upper right hidden switch (®)
until the display reads UNITS. Release the switch,
then press and release the switch until the display
reads REVIEW RECIPES.
2. Press YES to proceed. The display should now
read:
NO NAME, along with MODIFY, SHOW and NEXT
(SINGLE brewers)
NO-NAME LEFT, along with MODIFY, SHOW and
NEXT (DUAL brewers).
3. Press and release NEXT to advance to the desired
coffee name to be modified.
4. Press and release MODIFY. The display should
read BREW OZ.
5. Press and release DONE. The display should read
3 BATCHES DONE?.
6. Press and release YES. The display should now
read % BYPASS.
7. Press and release DONE. The display should read
3 BATCHES DONE?.
8. Press and release YES. The display should now
read SET PULSE BREW.
9. Press and release YES. The display should now
read EASY PULSE SETUP.
10. If setting pulse brew using EASY PULSE (brewing
into a funnel) press YES and proceed with the setup
instructions for SETTING PULSE BREW - EASY
PULSE SETUP.
11. If setting pulse brew by ENTER TIMES (entering
known times) press NO. The display should read
ENTER TIMES. Press and release YES and proceed
with the he setup instructions for SETTING PULSE
BREW - ENTER TIMES..
41342 080108
