Table : Burnham Vent System Components
Table 4: Vent Length
Vent System Component Part Number
Equivalent
Feet of Pipe
3” Dia. Pipe x 1 Ft 8116296U
1
4” Dia. Pipe x 1 Ft 100176-01
3” Dia. Pipe x 3 Ft 8116298U
3
4” Dia. Pipe x 3 Ft 100177-01
3” Dia. Pipe x 5 Ft 8116300U
5
4” Dia. Pipe x 5 Ft 100178-01
3” Dia. Pipe x Adjustable 8116319U Equal to
Installed Length
(1.06 TO 1.64)
4” Dia. Pipe x Adjustable 100179-01
3” Dia. 90° Elbow 8116294U
5
4” Dia. 90° Elbow 100180-01
3” Dia. 45° Elbow 8116292U
5
4” Dia. 45° Elbow 100181-01
3” Dia. Horizontal Drain Tee 8116302U
2
4” Dia. Horizontal Drain Tee 100182-01
3” Dia. Vertical Drain Tee 8116304U
7½
4” Dia. Vertical Drain Tee 100183-01
3” Single Wall Thimble 8116116
---
4” Single Wall Thimble 100184-01
3” Double Wall Thimble 8116115
---
4” Double Wall Thimble 100185-01
Model
3” Vent Pipe
(Equiv. Ft.)
4” Vent Pipe
(Equiv. Ft.)
Min. Max. Min. Max.
PVG-3 & PVG-4 8 50 --- ---
PVG-5 & PVG-6 8 50 --- ---
PVG-7 8 50 --- ---
PVG-8 & PVG-9 --- --- 8 40
